Model No. | Pipe Size | Orifice Size | CV Flow Factor | Operating Pressure Differential (PSI) | Maximum Fluid Temperature | |||||||
8210B54 | Minimum | Maximum | ||||||||||
1" | 1" | 13 | 0 | Air Inert Gas | Water | Light Oil @ 300 SSU | ||||||
AC | DC | AC | DC | AC | DC | AC | DC | |||||
125 | 100 | 125 | 100 | 125 | 80 | 180 | 77 |
CV Flow Capacity | 13 Cv |
---|---|
Orifice Size | 1 inch |
Pipe Size | 1 inch |
Operating Pressure Differential | 0 to 125 PSI |
Valve Outlet | 2-Way |
Valve Operation | Normally Closed |
Body Material | Brass |
