The Copeland ZR48K5E-PFV-800 is a single-phase scroll compressor operating at 208-230V and 60 Hz. Engineered for systems using either R22 or R407C refrigerants and delivers a cooling capacity of 48,200 BTU/hr. CE marked and UL recognized, ensuring compliance with international safety standards.
It features a 1/2" discharge line and a 7/8" suction line, and comes pre-charged with polyolester (POE) oil for enhanced lubrication. The compressor runs with a 60 MFD/440V capacitor and has an RLA (Rated Load Amps) of 24.3 and an LRA (Locked Rotor Amps) of 137.0, providing dependable performance.
The ZR48K5E-PFV-800 is a direct replacement for the Trane COM11200, making it a reliable solution for both new installations and service replacements. It is suitable for commercial or residential air conditioning and refrigeration applications.
| Connection Type | Stub |
|---|---|
| Power Ratings | 208/230V, 60 Hz |
| ARI Capacity | 48,200 Btu/hr |
| Amperage | 24.3 RLA, 137.0 LRA |
| Number of Phase | Single-Phase |
| Run Capacitor | 60 MFD/440V |
| Oil Type | Polyolester (POE) |
| Suction Size | 7/8" |
| Refrigerant Type | R22 or R407C |
| Discharge Size | 1/2" |
