| Mechanical Output | 280 lb-in (32 Nm) |
|---|---|
| Input Signal | 0 (2) to 10 VDC, 0 (4) to 20 VDC, or 0 (4) to 20 mA |
| Rotation Timing | 140 sec. at 50% rated load, 115 to 205 sec. for 0 to 280 lb·in (0 to 32 Nm) |
| Cycle Life | 60,000 full stroke cycles |
| Enclosure | NEMA 2, IP42 |
| Control Input Impedance | 205k Ohms |
| Feedback Signal | 0 to 10 VDC or 2 to 10 VDC for 90° (10 VDC at 1 mA) |
| Rotation Range | 0 to 90° in 5° increments, mechanically limited to 93° |
| Audible Noise Rating | 45 dBA at 1 m |
| Power Supply | AC 20 to 30 V at 50/60 Hz or DC 24 V ±10%; 7.5 VA supply minimum; Class 2 |
Download Product Information:
By Glenn
from
Yes, I would recommend this product to a friend or co-worker
Product was easy to order, arrived on time, and is working as designed.
