| Accuracy: | ±.20% FS (includes non-linearity, hysteresis and non-repeatability). |
|---|---|
| Temperature Limits: | -40 to 260°F (-40 to 125°C) 10 to 90% RH, non-condensing. |
| Compensated Temperature Range: | 20 to 180°F (-7 to 80°C). |
| Thermal Effect: | Zero and span shift: ±2.0% FS/100°F (% FS/50°C). |
| Power Requirements: | 9-30 VDC. |
| Output Signal: | 4-20 mA, 2-wire. |
| Zero and Span Adjustment: | ±0.5 mA, non-interactive. |
| Response Time: | ≤10 ms. |
| Loop Resistance: | 800 ohms. |
| Electrical Connections: | 1/2" conduit fitting and strain relief with 15 ft (4.5 m) cable. |
