Erie 0453L0077GB00 Light Duty 2-Way Spring Return Damper Actuator Direct Drive Clockwise Rotation 18" Lead 110-120 V 50/60 Hz

Name: Erie 0453L0077GB00 Light Duty 2-Way Spring Return Damper Actuator Direct Drive Clockwise Rotation 18" Lead 110-120 V 50/60 Hz
Brand: Erie
SKU: 0453L0077GB00
Price: 132.89 USD
Availability: InStock

Images for general purposes only. Actual may be different than depicted.

Erie 0453L0077GB00 Light Duty 2-Way Spring Return Damper Actuator Direct Drive Clockwise Rotation 18" Lead 110-120 V 50/60 Hz

SKU: 0453L0077GB00

Brand:

Rating:

Quantity	Price	Stock
13 Usually Ships 1 - 2 Weeks	$132.89 /ea	13

Buy in Bulk & Save

Quantity	Price
5+	$126.25 /ea

Add to Cart

Add to Wishlist

Add to Cart

Add to Wishlist

The 0453L0077GB00 is a light-duty 2-way spring return damper actuator that operates at 110 to 120V and 50/60 Hz frequency. It has a direct drive with clockwise rotation and includes 18" leads for easy wiring. CE-marked, UL-recognized, and CSA-certified.

The light-duty damper actuator is designed for two-position, spring-return damper applications. The unit is used to control the damper by opening or closing it. It also has a NEMA 1 protection rating that allows excellent durability.

The 0453L0077GB00 is easy to install with simple 2-wire thermostat control that makes it versatile for various installations

Voltage	110 to 120V
Frequency	50/60 Hz
Rotation	Clockwise
Lead Length	18"
Operating Temperature	0 to 120°F (-17 to 49°C)
Humidity	Non-condensing
Protection Rating	NEMA 1
Torque Rating	45 in-oz
Approvals	CE-marked, UL-recognized, and CSA-certified

Download Product Information:

Erie 0453L0077GB00 Two-Position Damper Actuator Technical Datasheet

Erie 0453L0077GB00 Two-Position Damper Actuator Installation Instructions
