Fenwal 35-665520-001 Microprocessor-Based Hot Surface Ignition Control with Inducer Blower Relay 30-Second Post-Purge 1 TFI 4-Seconds

Fenwal 35-665520-001 Microprocessor-Based Hot Surface Ignition Control with Inducer Blower Relay 30-Second Post-Purge 1 TFI 4-Seconds
Images for general purposes only. Actual may be different than depicted.
Fenwal 35-665520-001 Microprocessor-Based Hot Surface Ignition Control with Inducer Blower Relay 30-Second Post-Purge 1 TFI 4-Seconds

Fenwal 35-665520-001 Microprocessor-Based Hot Surface Ignition Control with Inducer Blower Relay 30-Second Post-Purge 1 TFI 4-Seconds

SKU: 35-665520-001
Rating:
Quantity Price Stock
Usually Ships 1-2 Weeks
Usually Ships 1-2 Weeks
$202.31     /ea
Usually Ships 1-2 Weeks
Order in multiples of 4
0
$0.00
0
$0.00
0
35-665520-001

The Fenwal 35-6x Series are 24VAC Microprocessor Based Gas Ignition Controls designed for use in all types of gas-fired equipment and appliances.



These controls utilize microprocessor technology to safely light and continually monitor and analyze the flame for proper operation of the gas burner. Value added-features include on-board combustion blower relay, pressure switch monitoring, alarm output, non-volatile lockout with manual reset, system LED diagnostics for troubleshooting, automatic one hour reset and flame current test pins.



Features

  • Direct Spark Ignition (DSI)
  • Hot Surface Ignition (HSI) or Proven HSI
  • Intermittent Pilot Ignition (IP)
  • Available with or w/o Combustion Blower
  • System Diagnostic LED
  • "Quick-Turn" Samples Availiable

Technical Specifications

  • Detect-A-Flame® Technology
  • Microprocessor Based for Precise Timings
  • Wide Range of Timing Options
  • Single or Multiple Tries for Ignition
  • Flame Sense Test Pins
  • Remote or Local Flame Sense

Listing & Approvals

  • c(CSA)us ANSI Z21.20
  • CAN/CSA C22.2 No. 199-M89
  • CE Approved to EN 298
  • Australian Gas AG206 and AG210
  • UL Component Recognized: UL 372
  • Software conforms to UL 1998

Download Product Information:

Series 35-66 Tech Sheet
