| Initial Dielectric Strength | Between Contacts & Coils: 2,200 VAC Between Poles: 2,200 VAC (includes shunt) Between Open Contacts: 2,200 VAC (no shunt) |
|---|---|
| Arc Cover | Optional on 20 – 30 FLA Standard on 40 FLA |
| Insulation System | 130°C Class B |
| Temperature Range | -40°F to +150°F (-40°C to +65°C) |
| Power Pole Terminations | #10-32 screw or box lug |
| Wire Size | #10-32 screw 16-8 (must use ring terminal) Box lug 14-4 |
| Recommended Tightening Torque | #10-32 screw: 22 in. lbs Box lug: 40 in. lbs |
Download Product Information:
Hartland Controls Contactor 1 and 2 Pole Specification Sheet
