1 in. NPT connection Air Purger.
Overview
Honeywell AP400 Series air purgers provide air and water separation in hydronic heating systems, improving efficiency and reducing noise. Solidly constructed of bronze, the air purgers feature tappings for expansion tank and auto air vent mounting.
Features
Heavy Duty cast iron construction
1 inch, 1 1/4 and 1 1/2 inch models (inlet and outlet)
1/2 inch bottom tapping for expansion tank mount
1/8 inch top tapping for air vent mount
Directional flow arrow for correct installation
Product Specifications
Application
Closed heating systems
Dimensions (in.)
6 in. long x 3-3/4 in. high x 2-3/8 in. wide
Dimensions (mm)
152 mm long x 95 mm high x 60 mm wide
Maximum Safe Operating Pressure (psi)
125 psi
Maximum Safe Operating Pressure (kPa)
862 kPa
Weight (lb)
4.2 lb
Weight (kg)
1.9 kg
Materials
Cast Iron
Operating Temperature Range (F)
275 F Maximum
Operating Temperature Range (C)
135 C Maximum
Connection Size (in.)
Bottom: 1/2 in.; Top: 1/8 in.
Connection Type
Female NPT
Pipe Size (inch)
1 in.
