Immersion well and case, 6 in. leadwires.
Overview
Temperature sensors are electronic sensors for use with chiller controls.
Features
Leadwires and wire nuts provided for wiring convenience.
Immersion well assembly provided for mounting in water supply.
Thermistor element provides accurate sensing of system water temperature changes.
Product Specifications
Application
Chilled water
Dimensions (in.)
2 3/4 in. high x 2 3/4 wide x 11 1/4 in. deep
Dimensions (mm)
70 mm high x 70 mm wide x 286 mm deep
Includes
6 in. leadwires
Used With
W901A
Item Type
Product
Sensor
Enclosure without sensor
Setpoint Temperature Range (C)
2 C to 13 C
Setpoint Temperature Range (F)
35 F to 55 F
Operating Temperature Range (F)
-40 F to +240 F
Operating Temperature Range (C)
-40 C to +116 C
Insertion Length (in.)
6 in., includes 3 inch insulation depth
Insertion Length (mm)
152 mm, includes 76 mm insulation depth
Ambient Temperature Range (F)
240 F Maximum
Ambient Temperature Range (C)
116 C Maximum
