Honeywell CTS-10-250-VDC-001 Solid Core Current Sensor with 0-10Vdc Output

Name: Honeywell CTS-10-250-VDC-001 Solid Core Current Sensor with 0-10Vdc Output
Brand: Honeywell
SKU: CTS-10-250-VDC-001
Price: 40.14 USD
Availability: OutOfStock

Images for general purposes only. Actual may be different than depicted.

Honeywell CTS-10-250-VDC-001 Solid Core Current Sensor with 0-10Vdc Output

SKU: CTS-10-250-VDC-001

Brand:

Rating:

Quantity	Price	Stock
Usually Ships 1-2 Weeks Usually Ships 1-2 Weeks	$40.14 /ea	Usually Ships 1-2 Weeks

Add to Cart

Add to Wishlist

Add to Cart

Add to Wishlist

Honeywell Solid Core Current Sensor

Depending on the model, current is converted into a linear and proportional output signal of 0-5 Vdc, 0-10 Vdc or 4-20 mA and monitored by a building management controller. These Fast acting current sensors are reliable and extremely easy to install.

Features

• Solid or split core loop-powered current transmitters for 4-20 mA models
• Solid or split core 0-5 or 0-10 Vdc models
• Fast response time
• Integral DIN rail mounting flange
• Easy wiring, polarity sensitive output
• Accepts up to a 350 MCM (17.3 mm) cable
• Operates up to 250 continuous amps
• True RMS versions are available
• RoHS and WEEE Complaint
• Limited 5 Year Warranty.

Frequency	50/60 Hz
Operating Humidity Range (% RH)	0 to 95% RH (non-condensing)
Supply Voltage	Induced from monitored conductor
Operating Temperature Range	5F to 104F (-15C to 40C)
Enclosure	UL94-5V Burgundy
Accuracy	Â±1.0% (5 to 100% FSO)
Core Type	Solid
Maximum Current	continuous--160 Amps; 320 Amps; 400 Amps: for 6 seconds--200 Amps; 400 Amps; 500 Amps;
Jumper Settings	Low; Middle; High
Output Switch Rating	0 to 10 VDC

Download Product Information:

Honeywell Solid Core and Split Core Current Sensors Product Datasheet

Honeywell Solid Core and Split Core Current Sensors Installation Instructions
