Honeywell M7294Q1007 Non-Spring Return Actuator

Name: Honeywell M7294Q1007 Non-Spring Return Actuator
Brand: Honeywell
SKU: M7294Q1007
Price: 2151.14 USD
Availability: InStock

Images for general purposes only. Actual may be different than depicted.

Honeywell M7294Q1007 Non-Spring Return Actuator

SKU: M7294Q1007

UPC: 0852670581

Brand:

Rating:

Quantity	Price	Stock
6 Usually Ships 1-2 Weeks	$2,151.14 /ea	6

Add to Cart

Add to Wishlist

Add to Cart

Add to Wishlist

Honeywell M7294Q1007 Actuator

The Series 72 Modutrol IV Motor spring return and non-spring return motor is used to control dampers and valves. The motor accepts a current or voltage signal from an electronic controller to position a damper or valve at any point between open and closed.

Features:

Integral spring return returns motor to normal position when power is interrupted.
Integral junction box provides NEMA 3 weather protection if motor is mounted in the upright position.
Motor and circuitry operate from 24 Vac.
Quick-connect terminals are standard--screw terminal adapter is available.
Adapter bracket for matching shaft height of older motors is available.
Motors have field adjustable stroke (90 to 160 degrees).
Integral auxiliary switches are available factory mounted, or can be field added.
Spring return motors can operate valve linkages from power end or auxiliary end shafts for normally closed or normally open valve applications.
All models have dual shafts (slotted and tapped on both ends).
All models have auxiliary switch cams.
Fixed torque throughout the entire voltage range.
Motors are designed for either normally open or normally closed valves and dampers.
Models available with adjustable start (zero) and span.
Models available with 4 to 20 mA input signal.
Models available with 2 to 10 Vdc input signal.
Die-cast aluminum housing.

Voltage	120 Vac
Shaft	Dual-ended square shaft
Rotation	90°F to 160°F field-adjustable stroke
Approvals	UL Listed, CE
Ambient Temperature	-40°F to 150°F (-40°C - 66°C)

Download Product Information:

Honeywell M7294Q1007 Actuator Data Sheet
