Honeywell MS8104F1210 Actuator Spring Return 24V
Fast-Acting, Two-Position Actuators are spring return direct coupled actuators (DCA) for Fire and Smoke dampers (on/off control). The actuator accepts an on/off signal from a single-pole, single-throw (SPST) controller. Reversible mounting allows actuator to be used for either clockwise (cw) or counterclockwise (ccw) spring rotation.
| Application | Fire and Smoke |
|---|---|
| Materials | Aluminum housing |
| Electrical Connections | Color-coded leads |
| Power Consumption | Driving-- 16VA, Holding-- 8 VA |
| Control Signal | Two position; SPST |
