Honeywell V800A1476 Standard Opening Standing Pilot Gas Valve 24V

Name: Honeywell V800A1476 Standard Opening Standing Pilot Gas Valve 24V
Brand: Honeywell
SKU: V800A1476
Price: 458.79 USD
Availability: OutOfStock

Images for general purposes only. Actual may be different than depicted.

Honeywell V800A1476 Standard Opening Standing Pilot Gas Valve 24V

SKU: V800A1476

Brand:

Rating:

Quantity	Price	Stock
Usually Ships 1-2 Weeks Usually Ships 1-2 Weeks	$458.79 /ea	Usually Ships 1-2 Weeks

Add to Cart

Add to Wishlist

Add to Cart

Add to Wishlist

The Honeywell V800A1476 is a single stage straight-through standard opening valve for natural gas. Used on gas fired standing pilot appliances with 30 mV thermocouple. These gas controls include a manual gas valve, safety shutoff, single millivoltage automatic operator, pressure regulator, pilot gas filter and flow adjustment, pressure tapping, and thermocouple connector.

Features

Include pilot flow adjustment screw.
Easy to install, adjust and service; all adjustments and connections are accessible from top of control.
Add separate energy cutoff (ECO) where codes call for dual safety shutoff.
Complete safety shutoff on pilot flame failure.
LITE-RITE (OFF-PILOT-ON) lighting sequence.
ECO connector for V800 models. Part No. 392451-1.

Mounting	0 to 90 degrees in any direction from the upright position of the gas control knob, including vertically0 to 90
Approvals	UL Component Recognized MCCZ2.MH5323; CSA International: 112395
Electrical Connection	Combination screw and 1/4" male quick connects
Pressure Rating	1/2 PSI (3.5 kPa)
Capacity	At 1 in. wc p.d.-- 250,000 BTU/hr: 23,000 BTU/hr minimum, 290,000 BTU/hr maximum
