Features

• Sizes from 2-1/2 in. to 6 in. with ANSI Class 125 flanged connections.
• Mixing or diverting control.
• Equal percentage or linear flow characteristics.
• Same flow pattern configuration as Globe valve.
• Can be used with Honeywell electronic actutors.
• Field configurable for normally open or normally closed fail-safe position.
• 2-1/2 and 3 in. valves have removable manual operating handle to control valve during installation or in an event of power failure.
• ANSI Class IV leakage specification (0.01% of CV). A to AB; ANSI Class IV leakage. B to AB; ANSI Class III leakage.
• Option of four actuator mounting positions on the valve for 4, 5 and 6 in. valves.
• Wide range of CV choices from 63 to 360.
• Valve ball and stem 316 stainless steelfor all valves except 3 in. valve..
