The Karl Dungs 228-770 Butterfly Control Valve 1-1/4" DMK 712/6 19 MM Orifice actuates on a 0 - 90 degree stroke in either direction. The valve does not close 100% and is not considered a tight shutoff valve and features direct mounting with most Karl Dungs shutoff valves.
Application:
The 228-770 is suitable for gas or air modulation on industrial and commercial heating applications. It can operate with natural gas, propane, butane, air and other inert gases. A recommended maximum pressure drop of 40" is suggested for optimum control through valve body. The 228-770 is designed for use with a Karl Dungs DMA actuator and screws directly to the downstream flange of the DMV.
For further details on technical specifications and selection, refer to the Data Sheet selection guide available under the Technical Data tab on this page.
The unit carries CE, UL and ULc approvals and is suitable for use in Canada, USA, the European Union.
| Maximum Pressure | 7 PSI (500 mbar) |
|---|---|
| Maximum Differential Pressure | 1.5 PSI (100 mbar) |
| Torque | Maximum 4.4 in-lb (50N cm) |
| Ambient Temperature | 5F to +140F (-15C to +60C) |
| Actuator Angle | 90 degrees from open to closed |
