Marktime 72146AB Heavy Duty 30-minute Timer. Includes Aluminum Wall Plate & Black Knob.
The MarkTime 70AB Series offers convenient timed control In-wall Heavy Duty Timers used for saunas, jacuzzi’s and pools, heavy-duty blower control, track lighting, industrial machinery, and other circuits requiring 28 Amp loads. The timers can fit in a double-gang wall box and replace a single-pole or double-pole wall switch for quick installation. These switch timers are perfect for residential and commercial purposes. Different time limits and switching configurations (DPST/SPDT) are available. We provide 1-year limited warranty.
ORDERING INFORMATION
DPST:
72130AB 60 Minute
72132AB 2 Hour
72134AB 5 Hour
72136AB 12 Hour
72144AB 15 Minute
72131AB 60 Minute,With Hold
72137AB 12 Hour, With Hold
SPDT:
74112AB 60 Minute
74114AB 2 Hour
74116AB 5 Hour
74118AB 12 Hour
74122AB 15 Minute
74124AB 30 Minute
74113AB 60 Minute, With Hold
74119AB 12 Hour, With Hold
| General Purpose | 28 AMP |
|---|---|
| Input | 120-240 VAC, 60 Hz |
| Motor | 1 Hp |
| Switch Configuration | DPST |
Download Product Information:
By Ken
from Salisbury MD
Yes, I would recommend this product to a friend or co-worker
So far it is working fine.
By Lana
from LOUISVILLE KY
Yes, I would recommend this product to a friend or co-worker
Works great, just what I was looking for.
Q & A: Ask the Questions, share answers
Do you have questions about this product?
Have an answer? Click Here
Yes, two Marktime 72146AB timers should be able to mount side by side in a standard 4 gang electrical box, since each timer is designed for a 2 gang box.
However, each timer is supplied with its own 2 gang aluminum wall plate, and Marktime does not list a standard 4 gang cover plate for mounting two of these timers together. A custom 4 gang cover plate would likely be required, or alternatively the timers can be installed in two separate 2 gang boxes.
The installation should be confirmed by a qualified electrician for box depth, box fill, wiring, and applicable electrical code requirements.
