Frequntly Asked Questions

• What is the Nordyne 1017206 used for?

The Nordyne 1017206 is used in compatible HVAC systems to control electric heater operation. It opens or closes the circuit when the relay coil is energized.

• What is the electrical rating of the Nordyne 1017206?

The Nordyne 1017206 has a 240V, 30A electrical rating with a 24V coil voltage.

• What type of relay circuit does the 1017206 use?

The 1017206 uses a normally open SPST circuit, which allows the relay to close the circuit when the coil is energized.

• Is the Nordyne 1017206 UL-recognized?

Yes. The Nordyne 1017206 relay kit is UL-recognized.

• What parts does the Nordyne 1017206 replace?

The Nordyne 1017206 directly replaces Nordyne 624843 and Honfa HF105F-4.

• Can the 1017206 be used for electric heater applications?

Yes. The Nordyne 1017206 is suitable for electric heater applications in compatible HVAC equipment.

• How does the heater relay kit work?

The relay responds to a 24V coil signal. When the coil is energized, the relay changes state and opens or closes the connected circuit to control the heating load.
