| Display | 8 Digit LCD, 9mm Characters |
|---|---|
| Storage Temperature | -20 to 60°C |
| Operating Temperature | -10 to 60°C |
| Material | Polycarbonate |
| Environmental Protection | IP65 |
| Count Range | 99999999 Display Rollover to 0 |
| Battery Life | 10 Years |
| Direction Input | Add=Logic 1, Subtract=Logic 0 (0V) |
| Reset Input | Negative Edge Triggered, 0.7V Threshold, 15mS Minimum Pulse Length |
| Count Input | 10kHz Maximum, Negative Edge Triggered, 0.7V Threshold, 50µS Minimum Pulse Length |
