Storage Temperature | -65 to 160°F (-54 to 71°C) |
---|---|
Ambient Temperature Limits | -40 to 160°F (-40 to 71°C); set point typically shifts less than 1% of range for a 50°F (28°C) ambient temperature change |
Set Point Repeatability | Temperature models: ± 2% of adjustable range; Pressure models: ± 2% of adjustable range |
Shock | Set point repeats after 15 G, 10 millisecond duration |
Vibration | Set point repeats after 2.5 G, 5-500 Hz |
Enclosure | Die cast aluminum, epoxy powder coated, gasketed, captive cover screws; Designed to meet enclosure type 4X requirements |
Electrical Rating | 15 A 125/250/480 VAC resistive. Electrical switches have limited DC capabilities. |
Electrical Connection | One 3/4†NPT and two 7/8†diameter knockouts |
