The Veris HW2XA2D wall humidity sensor provides accurate relative humidity and temperature monitoring for commercial HVAC and building automation systems. Its ±2% RH sensing accuracy and 10K Ω Type 2 thermistor support precise environmental control, improved occupant comfort, and efficient system performance. The replaceable thin-film capacitive element measures 0 to 100% RH with 0.1% resolution and recovers from full saturation to reduce maintenance downtime.
For broad BAS compatibility, the HW2XA2D offers selectable 4 to 20 mA, 0 to 5 V, and 0 to 10 V analog outputs. It operates on 24 VAC, ±20%, at 50/60 Hz with a 2.0 VA power requirement and Class 2 wiring.
The sensor is rated for air exposure from -40°F to 140°F, with normal operation specified from 32°F to 122°F and 0 to 95% RH non-condensing.
A matte-white, high-impact ABS enclosure, IP20 protection, and screw terminals for 18 to 24 AWG wiring support dependable wall-mounted installation.
UL Listed, CE, and UKCA markings, along with EN61000 Series industrial immunity compliance, make the sensor suitable for offices, schools, museums, workshops, and other facilities requiring reliable humidity and temperature control.
Veris HW2XA2D directly replaces HWX3XSTD Sensor.
Frequently Asked Questions
What does the Veris HW2XA2D measure?
The HW2XA2D measures relative humidity and temperature for HVAC and building automation applications.
The sensor provides ±2% RH accuracy from 10% to 80% RH at 77°F.
The HW2XA2D includes a 10K Ω Type 2 thermistor.
The sensor supports selectable 4 to 20 mA, 0 to 5 V, and 0 to 10 V analog outputs.
It operates on 24 VAC, ±20%, at 50/60 Hz with a 2.0 VA power requirement and Class 2 wiring.
Yes. The thin-film capacitive humidity sensing element is field replaceable.
The screw terminals accept 18 to 24 AWG wiring.
It is suitable for offices, schools, museums, workshops, and other commercial facilities requiring humidity and temperature monitoring.
The sensor has an IP20-rated, high-impact ABS enclosure.
The HW2XA2D carries UL Listed, CE, and UKCA markings and complies with EN61000 Series industrial immunity requirements.
Yes. Veris HW2XA2D directly replaces HWX3XSTD Sensor.
| Humidity Accuracy | ±2% relative humidity (RH) measurement |
|---|---|
| Temperature Sensor Type | Integrated 10K Ohm Type 2 Thermistor |
| Mounting Type | Room wall-mount |
| Air Temperature Range | -40 to 140°F / -40 to 60°C |
| Supply Voltage | 24 VAC ±20% |
| Frequency | 50/60 Hz |
| Power | 2.0 VA |
| Certifications | UL Listed , CE |
Download Product Information:
Veris HW2XA2D Wall Humidity Sensor ±2% 2% Accuracy 10K Ω Type 2 Thermistor Instruction Manual
