Watts Series LFDPTG-1 Combination Pressure and Temperature Gauges
Series LFDPTG-1 Combination Pressure and Temperature Gauges are used in commercial, residential, and institutional HVAC applications. These gauges are bottom-entry type models with black enamel steel cases, Kostil Polymer windows, 1/2" NPT connections, copper alloy Bourdon tube pressure elements, and bimetal spiral springs. The LFDPTG-1 features Lead Free* construction to comply with Lead Free* installation requirements. Accuracy is ASME, Type B. The Series LFDPTG-1 gauges are available in various pressure rating scales. The dual pressure scale features PSI and kPa measurements. The dual temperature scale features ºF and ºC measurements.
This 0121664 gauge features a 3 inch dial with pressure rating scale from 0 to 75 psi and temperature range 32 to 248 degrees F.
FEATURES:
| Connection Size | 1/2 inch |
|---|---|
| Dial Size | 3 inch |
| Scale | 0 – 75psi 517 kPa |
| Working Temperature | 60°F to 320°F (15.5°C to 160°C) |
| Case Material | Black enamel steel |
| Window Material | Kostil polymer |
| Pressure Element Material | Copper alloy Bourdon tube |
| Temperature Element Material | Bimetal spiral spring |
| Welding Material | Tin alloy |
| Connector Material | Lead Free Brass |
Download Product Information:
Watts Series LFDPTG-1 Combination Pressure and Temperature Gauges Technical Datasheet
