Series LF957RPDA Reduced Pressure Detector Assemblies provide protection to the potable water system from contamination in accordance with national plumbing codes. The LF957RPDA are normally used in health hazard applications to protect against backsiphonage and backpressure. The Watts LF957RPDA are used to monitor unauthorized use of water from the fire protection system. They feature Lead Free construction to comply with Lead Free* installation requirements.

This 0122742 lead free reduced pressure detector assembly is a 2 1/2 inch in connection size. It has UL/FM outside stem and yoke, resilient seated gate valves. It consists of domestic osy shutoff valves and less meter.

• Lead Free construction
• Extremely compact design
• 70% lighter than traditional designs
• 304 (Schedule 40) stainless steel housing & sleeve
• Groove fittings allow integral pipeline adjustment
• Patented torsion spring check provides lowest pressure loss
• Unmatched ease of serviceability
• Replaceable check disc rubber
• Available with grooved butterfly valve shutoffs
• Bottom mounted cast stainless steel relief valve
• Metered bypass to detect leakage or theft of water from the fire sprinkler system
