Watts 0546845 FBV-3C 4" Full Port Brass Ball Valve

Name: Watts 0546845 FBV-3C 4" Full Port Brass Ball Valve
Brand: Watts
SKU: 0546845
Price: 628.66 USD
Availability: OutOfStock

Images for general purposes only. Actual may be different than depicted.

Watts 0546845 FBV-3C 4" Full Port Brass Ball Valve

SKU: 0546845

Brand:

Rating:

Quantity	Price	Stock
Usually Ships 1-2 Weeks Usually Ships 1-2 Weeks	$628.66 /ea	Usually Ships 1-2 Weeks

Add to Cart

Add to Wishlist

Add to Cart

Add to Wishlist

Watts Series FBV-3C Full Port Brass Ball Valves

Series FBV-3C & FBVS-3C 2-Piece, Full Port, Brass Ball Valves are used in commercial and industrial applications for a full range of liquids and gases. They feature a bottom-loaded blowout-proof stem, virgin PTFE seats, thrust washer, and adjustable stem packing gland, stem packing nut, chrome plated brass ball, brass adapter, and steel handle. Model FBV-3C has threaded end connections. Model FBV-3C-TH has tee handle with threaded and solder connections. Model FBVS-3C has solder end connections. Pressure Rating for 1/4 in. ‒ 2 in. (8 ‒ 50mm) is 600psi WOG and 150psi WSP. 2 1/2 in. to 4 in. (35 ‒ 100mm) is 400psi WOG and 125psi WSP.

Features:

Fluorocarbon elastomer stem O-ring prevents stem leaks
Used in commercial and industrial applications for a full range of liquids and gases
Available in several sizes with solder and threaded end connections
Recommended for open/close applications

Control Type	Lever Handle
Inlet/Outlet Connection Type	Female Threaded
Body Material	Brass
Pressure Ratings	400psi (27.5 bar) WOG, non-shock 125psi (8.6 bar) WSP
Water Temperature Range	-40ÂºF to 400ÂºF (-40ÂºC to 204ÂºC)
Inlet/Outlet Connection Size	4 in
Inlet Thread Type	NPT
Outlet Thread Type	FPT

Download Product Information:

Watts FBV-3C & FBVS-3C Series Full Port Brass Ball Valves Technical Datasheet
