| Part No. | Description | Part No. | Description |
| MS-DIS1710-0 | Local Controller Display LCD Control | TL-BRTRP-000C | Bacnet Commissioning Adapter |
| Y65T31-0 | Transformer 120/280/240V Primary 24V Secondary | Y65T42-0 | Transformer 120/208/240V Primary 24V Secondary |
| AS-XFR050-0 | Transformer Primary 120V Secondary 24V | Y65A13-0 | Transformer Primary 120V Secondary 24V |
| AP-TBK4SA-0 | Bus Terminal, 4-Position Connector | TL-BRTRP-0 | Portable Bacnet Router |
| AP-TBK4FC-0 | MS/TP FC Bus Terminal, 4 Position Connector | MS-BTCVTCBL-700 | Cable |
| AP-TBK3PW-0 | Power Terminal, 3-Position Connector | FX-BTCVT-1 | Wireless Commissioning Tool |
| WRZ-SST-120 | Wireless Sensing System Tool | Y64T15-0 | Transformer |
| ZFR-USBHA-0 | USB Dongle with Zigbee Drive | FX-WRZ7860-0 | Wireless Receiver One To One |
| Input/output Terminals | Fixed Screw Terminal Blocks |
|---|---|
| Protection Class | IP20 (IEC529) |
| Enclosure Material | ABS and polycarbonate |
| Ambient Operating Condition | 32°F to 122°F (0°C to 50°C) 10% to 90% RH |
| Mounting | Horizontal or Vertical |
| Voltage | 24V |
| Frequency | 50/60 Hz |
| Maximum Power Consumption | 13 VA |
| Memory | 16 MB Flash Memory and 8 MB RAM |
| Approvals | CE-marked, UL-listed, and CSA-certified |
