BAPI BA/SFC2000-1000 Sealant Filled Connector is used for wire protection from moisture and oxidation. A small connector that can help prevent possible fire, electrocution, and flashover.
The SFC2000 is a twist-on type connector that can accept two 22 AWG wires or one 22 AWG and one 16 or 18 AWG wire. Operating temperature must not exceed 221°F (105ºC).
Available in different quantities: 100, 500, and 1000 pieces.
Also, BAPI offers three types of SFCs that you can choose from:
| BAPI Sealant Filled Connectors | ||
| Model No. | Type | Quantity (pcs) |
| SFC1000-100 | Crimp-On | 100 |
| SFC1000-500 | Crimp-On | 500 |
| SFC1000-1000 | Crimp-On | 1000 |
| SFC2000-100 | Twist-On | 100 |
| SFC2000-500 | Twist-On | 500 |
| SFC2000-1000 | Twist-On | 1000 |
| SFC3000-100 | Crimp-On | 100 |
| SFC3000-500 | Crimp-On | 500 |
| SFC3000-1000 | Crimp-On | 1000 |
| Connector Style | Twist-On |
|---|---|
| Wire Gauge | two 22 AWG wires or one 22 AWG and one 16 or 18 AWG wire |
| Voltage Rating | 300V |
| Operating Temperature | not exceed 221°F (105ºC) |
| Color | Blue |
Download Product Information:
