Honeywell Q7230A1005 Interface Module is a solid-state electronic adapter designed to convert Series 90 Modutrol IV motors for Series 70 electronic control applications.

It accepts 2–10 VDC or 4–20 mA control signals and connects directly to the motor’s quick-connect terminals inside the wiring box, helping reduce retrofit complexity and simplify control-system modernization.

Field-adjustable zero and span settings support accurate calibration, while the motor’s NEMA 3R wiring enclosure helps protect the installed module from weather exposure.

This interface module is well suited for HVAC damper and valve control upgrades where an existing Series 90 Modutrol IV motor must operate with modern electronic control signals.

Order the correct components today to complete a Honeywell actuator control solution.

Honeywell Q7230A1005, Honeywell M9185D1004, and Honeywell 50017460-003 together directly replace the M7285Q1008 Damper Actuator and must be purchased separately to form a complete replacement..


Frequently Asked Questions


• What does the Honeywell Q7230A1005 Interface Module do?

The Honeywell Q7230A1005 is a solid-state electronic adapter that allows a Series 90 Modutrol IV motor to operate with Series 70 electronic control signals.

• What control signals does the Q7230A1005 accept?

The module accepts 2–10 VDC or 4–20 mA control signals for compatible HVAC damper and valve control applications.

• How is the Honeywell Q7230A1005 installed?

The interface module connects directly to the motor’s quick-connect terminals inside the wiring box, helping simplify installation and retrofit work.

• Can the Q7230A1005 be adjusted during installation?

Yes. Field-adjustable zero and span settings allow the module to be calibrated for the control application.

• Is the Q7230A1005 suitable for HVAC retrofit projects?

Yes. It is well suited for applications where an existing Series 90 Modutrol IV motor must be adapted for use with a Series 70 electronic control system.

• Does the Q7230A1005 include the complete M7285Q1008 Damper Actuator?

No. Honeywell Q7230A1005, Honeywell M9185D1004, and Honeywell 50017460-003 must be purchased separately to form a complete M7285Q1008 Damper Actuator.

• Are the required companion components sold separately?

Yes. Confirm that all required Honeywell components are ordered before installation to complete the actuator control assembly.
